HAZET · TORQUE SCREWDRIVER
HAZET 6005CT-60 Torque Screwdriver
The HAZET 6005CT-60 is designed for controlled tightening with adjustable torque settings from 1 to 6 N·m. It offers a torque accuracy of ±6% and a scale graduation of 0.1 N·m. The micrometer scale calibrated in N·m makes the selected torque setting easy to read.
Key Features
- Torque range: 1–6 N·m
- Torque accuracy: ±6%
- Scale graduation: 0.1 N·m
- Micrometer scale calibrated in N·m
- 1/4" female hexagon bit holder
- Ratchet mechanism
- Ergonomic T-handle
- Tested in accordance with DIN EN ISO 6789-2:2017
- Length: 198 mm Weight: 0.3 kg
- HAZET factory calibration certificate
- Manufacturer / Origin: Hazet / Germany
- Technical support provided by Surkon
Controlled Tightening and Precise Torque Setting
The HAZET 6005CT-60 is designed for controlled tightening with adjustable torque settings from 1 to 6 N·m. It offers a torque accuracy of ±6% and a scale graduation of 0.1 N·m. The micrometer scale calibrated in N·m makes the selected torque setting easy to read.
The screwdriver features a 1/4" female hexagon bit holder, a ratchet mechanism and an ergonomic T-handle. Measuring 198 mm in length and weighing 0.3 kg, it is supplied with a HAZET factory calibration certificate. Technical support is provided by Surkon.
Model Comparison
| Model | Torque Range (N·m) |
Torque Range (cN·m) |
Hexagon Drive | Length (mm) |
Weight (kg) |
|---|---|---|---|---|---|
| 6005CT-60 | 1–6 | 100–600 | 1/4" female hexagon | 198 | 0.3 |
| 6005CT-100 | 4–10 | 400–1000 | 1/4" female hexagon | 198 | 0.3 |
On smaller screens, scroll horizontally to view the full table.
Product Detail Images
HAZET 6005CT-60 – Frequently Asked Questions
What is the Hazet 6005CT-60 torque screwdriver used for?
The HAZET 6005CT-60 is used to tighten screw connections to a specified torque between 1 and 6 N·m. It allows the tightening torque specified in the technical documentation for the connection to be applied during assembly and maintenance.
What is the difference between the HAZET 6005CT-60 and 6005CT-100?
The main difference is the torque range. The HAZET 6005CT-60 operates from 1 to 6 N·m, while the HAZET 6005CT-100 operates from 4 to 10 N·m. Select the model according to the torque required for the connection being tightened.
What happens when the Hazet 6005CT-60 reaches the set torque?
When the set torque is reached, the mechanism releases with an audible and tactile signal. The slipping clutch prevents the set torque from being exceeded during clockwise tightening.
Which screwdriver bits are compatible with the Hazet 6005CT-60?
The 1/4" female hexagon bit holder accepts bits with D 6.3 / F 6.3 shanks. Select the bit profile and size to match the screw head.
Does the HAZET 6005CT-60 also provide torque control during anticlockwise tightening?
No. The specified torque accuracy and torque-limiting function apply to clockwise tightening only. Anticlockwise rotation allows loosening without torque limitation.
What is the torque accuracy of the HAZET 6005CT-60?
The torque accuracy is ±6% of the set scale value during clockwise tightening. The scale graduation is 0.1 N·m. Scale graduation and torque accuracy are different technical specifications.
Can the HAZET 6005CT-60 be calibrated?
Yes. Calibration services and technical support for the HAZET 6005CT-60 are provided by Surkon. Contact Surkon to discuss the calibration scope and your certificate requirements. Surkon is an authorised HAZET dealer and technical support provider in Türkiye. Repair, maintenance and calibration services for HAZET equipment are provided by Surkon. An in-house calibration certificate is issued for HAZET torque wrenches following repair and maintenance. TÜRKAK-accredited calibration services are available on request at the Surkon calibration laboratory.
Product Video
Specifications
| Brand | Hazet |
| Operation Type | Manual |
| Accuracy | ±%6 |
