HAZET · TORQUE SCREWDRIVER
HAZET 6004CT-12 Precision Torque Screwdriver
Adjustable precision torque screwdriver with a standard handle and a torque range of 0.1–1.2 N·m
Key Features
- Torque range: 0,1–1,2 N·m / 20–120 cN·m
- Torque accuracy: ±6% of the set value during clockwise tightening
- Scale graduation: 1 cN·m / 0.01 N·m
- Large, easy-to-read numerical torque setting display
- 1/4" female hexagon bit holder
- Magnetic quick-change bit holder with mechanical locking
- Clockwise / anticlockwise / fixed ratchet modes
- Slipping clutch prevents the set torque from being exceeded during clockwise tightening
- 36° release angle with audible and tactile release
- Ergonomic HAZET 2-component handle
- Tested in accordance with DIN EN ISO 6789-2:2017
- Length: 196 mm · Weight: 0.2 kg
- HAZET factory calibration certificate
- Manufacturer / Country of origin: HAZET / Germany
- Technical support, spare parts and calibration services provided by Surkon
Controlled Tightening at Low Torque
The HAZET 6004CT-12 is designed for controlled tightening of screw connections requiring low torque. With an adjustable torque range of 0.1–1.2 N·m and an accuracy of ±6% during clockwise tightening, it is suitable for precision assembly work. The large numerical display makes the selected torque setting easy to read. The scale graduation is 1 cN·m, equivalent to 0.01 N·m.
The ratchet mechanism offers clockwise, anticlockwise and fixed modes, allowing smooth regripping, particularly in confined spaces. When the set torque is reached, the mechanism releases with an audible and tactile signal.
The slipping clutch prevents the set torque from being exceeded during clockwise tightening. Anticlockwise rotation allows loosening without torque limitation.
The 1/4" female hexagon bit holder accepts bits with D 6.3 / F 6.3 shanks. The magnetic holder and mechanical locking system allow quick, one-handed bit changes. The release mechanism is made of high-alloy tool steel for wear resistance.
The ergonomic 2-component handle combines glass-fibre-reinforced plastic with soft TPE grip zones for a comfortable, controlled grip. The screwdriver measures 196 mm in length and is manufactured in Germany. It is tested in accordance with DIN EN ISO 6789-2:2017.
Supplied with a HAZET factory calibration certificate. Technical support, spare parts and calibration services in Türkiye are provided by Surkon.
Model Comparison
| Model | Torque Range (N·m) |
Torque Range (cN·m) |
Hexagon Driver | Length (mm) |
Weight (kg) |
|---|---|---|---|---|---|
| 6004CT-12 | 0.1–1.2 | 10–120 | 1/4" female hex | 196 | 0.2 |
| 6004CT-3 | 0.02–0.3 | 2–30 | 1/4" female hex | 196 | 0.2 |
| 6004CT-60 | 1–6 | 100–600 | 1/4" female hex | 196 | 0.2 |
On smaller screens, you can scroll the table horizontally.
Product Detail Image
Documents
Hazet 6004CT-12 – Frequently Asked Questions
What is the Hazet 6004CT-12 used for?
It is used to tighten screw connections that require low torque with a specified torque in the range of 0.2–1.2 N·m. The torque value to be used should be selected according to the technical documentation of the connection.
What is the difference between 6004CT-12 and 6004CT-3?
The main difference is the torque range. 6004CT-12 has a range of 0.2–1.2 N·m; 6004CT-3 has a range of 0.02–0.3 N·m. Model selection should be made according to the torque value required by the connection.
What happens when the set torque is reached?
The mechanism is triggered audibly and noticeably. The slip clutch that operates in the tightening direction prevents exceeding the set torque.
Does it provide torque control when turning left?
No. The specified precision and torque limiting function is valid for the tightening direction to the right. Loosening can be done without torque limitation when turning left.
Which screwdriver bits are compatible?
The 1/4″ female hex bit holder is compatible with bits that have D 6.3 / F 6.3 connections. The profile and size of the bit should be selected according to the screw head.
What is the scale value?
The scale value is 0.01 N·m. This value is equal to 1 cN·m. The scale value represents the adjustment step; it is a different feature from the ±6% torque accuracy.
Is calibration and technical support provided?
Yes. Technical support, spare parts, and calibration services for Hazet 6004CT-12 are provided by Surkon.
Surkon is the authorized dealer and technical support point for the Hazet brand in Turkey. All repair, maintenance, and calibration services for Hazet devices are provided by Surkon.
Hazet torque wrenches issue an internal calibration certificate after the repair and maintenance process. If requested, Turkish accredited calibration services are offered at the Surkon calibration laboratory.
Product Video – HAZET Torque Screwdriver Series
Specifications
| Brand | Hazet |
| Operation Type | Manual |
| Accuracy | ±%6 |
